Uv Spatial Light Modulator Window

Our reflective lcos liquid crystal on silicon is an advanced spatial light modulator for full high resolution applications.

Uv spatial light modulator window. The pluto 2 1 phase only spatial light modulator slm consists of a driver unit with standard digital video interface hdmi and a phase only lcos liquid crystal on silicon microdisplay with full hd resolution 1920 x 1080 pixel and 8 µm pixel pitch leading to an active area diagonal of 0 7 with aspect ratio of 16 9. A spatial light modulator slm is an object that imposes some form of spatially varying modulation on a beam of light. The dlp95000uv chipset is a new digital micromirror device dmd addition to the dlp discovery 4100 platform which enables highresolution and high performance spatial light modulation beyond the visible spectrum into the uvaspectrum 363 nm to 420 nm. Its unique combination of speed accuracy reliability and manufacturability has been field proven in demanding applications.

When coupled to an appropriate optical system the dlp9500uv can be used to modulate the amplitude direction and or phase of incoming light. The dlp9500uv dmd is designed with a special window that is optimizedfor uv transmission. The full high definition full hd resolution 10 bit 1024 gray levels and excellent phase stability 0 003π rad make ultra fine light modulation possible for various applications. This product is a world s first for two dimensional slm extending their use into the uv band.

A power density up to 10 mw cm 2 is sustainable using a novel liquid crystal and dielectric mirror design. The uv hardened slm 250 has 42 times uv durability when compared to standard slm. The slm150 is a 2d spatial light modulator with 42 higher uv durability when compared to standard devices. Open in new find other ultraviolet uv chipsets description.

Liquid crystal based spatial light modulator ultra violet and full hd model slm 250 santec introduces an ultra violet uv durable spatial light modulator slm 250. Is based on liquid crystal on silicon lcos technology. A simple example is an overhead projector transparency usually when the phrase slm is used it means that the transparency can be controlled by a computer in the 1980s large slms were placed on overhead projectors to project computer monitor contents to the screen. Lc 2012 translucent spatial light modulator the lc 2012 is a basic spatial light modulator system based on a translucent liquid crystal microdisplay with a resolution of 1024 x 768 pixel xga.

The device can be used for phase or amplitude modulation in the visible range however phase shift may be limited e g.
